Wfs1071aw-7.5kg Instruction Manual

WASHER WILL NOT START: Power If your washing machine won't start, begin by looking at the power source. First of all, is the washing machine plugged in? If it is, has it tripped a circuit breaker or blown a fuse?

Mar 26, 2011. I have a WFS1071AW-7.5kg' front loading washing machine and the 'clean pump' light keeps coming on mid cycle. What do i need to do to correct this error / issue? It interrupts the wash cycle such that i have to keep pushing the start button to complete the cycle. The clean pump light is only coming on. WHIRLPOOL WASHING MACHINE -FOR PARTS - WFS1071AW 7.5KG. $40.00 Negotiable. HI THE WHIRLPOOL WASHING MACHINE WE HAVE HERE HAS BEEN A GOOD WASHER. Instruction manual/user guide included. Dimensions: 840mm H x 600mm W x 590mm D. Selling as I have upgraded to a larger machine.

Check and reset the breaker (or replace the fuse) if necessary. Lid Switch The main control for the washing machine is the switch inside the lid. If this has stopped working for some reason, your washing machine won't start. It's not especially difficult to troubleshoot this on a washing machine. You might have to open the top to access the switch.

With the power on, depress the switch and listen for a click. If you don't hear one, the switch MAY BE BAD and will need to be replaced. Confirm defectiveness with a multi meter checking for continuity OHMS. An open circuit reflects a bad switch. How To Program Caddx Nx 8 Troubleshooting on this page.

If the switch works but the washing machine still won't start, check to see if your washing machine has a special fuse for the lid switch. It will usually be inside the control panel. If it's blown, you'll need to replace it before the washing machine will start.

Door Interlock The problem could be with the door interlock. If the lights come on but the machine won't start, this might well be the cause. This could either be down to the wiring that runs to the door interlock, or the door catch not activating the interlock itself.

Timer Knob Some models of washing machine use a mechanical timer knob and won't run until the water in the machine has filled to the selected level. If the knob doesn't line up properly with the graphics on the control panel, you can try to troubleshoot the washing machine problem by advancing the timer a little. When you've done this, pull it out a little way and see if the washing machine will start properly. Push start switch may need to be tested with a multi meter for continuity OHMS should show a closed circuit when pushed in or turned on. The start switch on some top load washers is often part of the timer and is activated by pulling out on the timer knob. Although not normally available as a separate part, the switch can be tested for continuity with a multi-meter.

You will need to remove power from the appliance and then locate the correct timer contacts as noted on the wiring diagram. On some electronic controlled models, the start switch is a momentary contact type switch located on the control console. You can test this switch for continuity with a multi-meter when the push button is held in Overheating If you've run several loads, one after another, without any problem but suddenly find your washing machine refuses to start, overheating could be the cause. The simple way to discover whether this is the problem is to give the machine ample time to cool down, say for a couple of hours, and then try it again. If it works fine, overheating has been the problem and you may have a motor with bad windings. By the way my advice is free cuz God is good!

All washing machines use a motor that is responsible for spinning and agitating during the cleaning cycle. Many top load brands use a reversing motor which means the motor spins in one direction for agitating and another for spinning and draining. If the motor does not start, but makes a humming or buzzing noise then it may be defective. To verify if the motor is at fault, remove the drive and /or pump belts and then try to start the motor again. On direct drive models, you will have to disengage the pump and the direct drive coupling to the transmission. If the motor starts, then the problem is with the transmission or the pump and can be further diagnosed by reconnecting each one individually. If the motor does not start or continues to hum or buzz, then it will need to be replaced Lastly CONTROL BOARD If the control board does not provide the proper voltage to the drive motor, fill valve, drain motor or door lock then the washer may not start.

The main control board on most washers is complicated and difficult to diagnose without proper test equipment and procedures. You can visually inspect the control for signs of electrical arcing or burned or damaged components on the board. You should use caution when replacing a control board as sometimes the burned components are caused by external component failures. The pump is hidden below the removable kick plate at the bottom of the machine. Hold the plinth on either side and pul it downwards and outwards to remove it. The filter is unscrewed by turning anticlockwise. This is covered in page 11 of your manual, a pathetically poor scanned PDF copy of which is supplied by whirlpool Australia if you go to this web address: Enter WFS1071AW As the commercial code and select language ENGLISH Note: This model has no drain hose to get rid of residual water, suggest you tip the machine back 45 degrees and have a towel ready to catch any leaked water.

Aug 23, 2011 . Hi and welcome to FixYa, I am Kelly. This is the WFS1071AW version of the manual and the pump cleaning instructions are the same: And then enter 'WFS1071' Instructions for removing the filter are on page 14 of the user manual.

(Wth pictures) Pump / Filter cleaning POWER OFF UNIT UNPLUGED: Basically you open the lower panel by pushing down and pulling toward you at the top. Use something like a cake pan for catching water. Grasp the CIRCULAR filter and rotate it COUNTER CLOCKWISE until the water starts draining. WAIT until all the water possible drains. Then unscrew the filter and pull it out. Clean out any debris. Make sure to reach deep into the filter hole and CAREFULLY clean off the sensor if you can reach it and then reinstall the filter by rotating clockwise.

Last steps install the lower panel and PLUG IN POWER. Full Driver Entegreli Xp. Thanks for choosing FixYa, Kelly Feb 24, 2011 .
